Back to Bike FinderYears: 2009 · 2007
2009Sportbike
Bimota DB5 S
Key specifications
Engine
1079 cc
Power
95 HP
Torque
103 Nm
Weight
185 kg
Fuel type
petrol
Fuel capacity
4.2 L
Transmission
6-speed
Seat height
32 mm
Front brakes
Double disc. Floating Discs Brembo, Radial Caliper Brembo 4-Pistons, 4-Pads
Rear brakes
Single disc. Brembo, 2-Pistons, 2-Pads Brembo
Technical details
Source specification data
- Make
- Bimota
- Model
- DB5 S
- Category
- Sport
- Color Options
- Red/white, yellow
- Power
- 95.00 HP (69.3 kW)) @ 7000 RPM
- Clutch
- Dry multi-plate with hydraulic control
- Torque
- 102.97 Nm (10.5 kgf-m or 76.0 ft.lbs) @ 5500 RPM
- Gearbox
- 6-speed
- Fuel System
- Injection
- Bore X Stroke
- 98.0 x 71.5 mm (3.9 x 2.8 inches)
- Compression
- 10.5:1
- Displacement
- 1079.00 ccm (65.84 cubic inches)
- Cooling System
- Air
- Engine Details
- V2, four-stroke
- Lubrication System
- Wet sump
- Valves Per Cylinder
- 2
- Transmission Type Final Drive
- Chain
- Dry Weight
- 185.0 kg (407.9 pounds)
- Seat Height
- 800 mm (31.5 inches) If adjustable, lowest setting.
- Fuel Capacity
- 16.00 litres (4.23 gallons)
- Overall Height
- 1,230 mm (48.4 inches)
- Overall Length
- 2,045 mm (80.5 inches)
- Ground Clearance
- 170 mm (6.7 inches)
- Power Weight Ratio
- 0.5135 HP/kg
- Rear Percentage Of Weight
- 49
- Front Percentage Of Weight
- 51
- Rake
- 24.0°
- Trail
- 108 mm (4.3 inches)
- Rear Tyre
- 180/55-17
- Frame Type
- CrMo steel tubular trellis
- Front Tyre
- 120/70-17
- Rear Brakes
- Single
- disc.
- Brembo
- , 2-
- Pistons
- , 2-
- Front Brakes
- Double
- disc.
- Floating Discs Brembo
- ,
- Radial Caliper Brembo
- 4-
- Pistons
- , 4-
- Rear Suspension
- Monoshock Extreme Tech Full Adjustable
- (
- Pre
- -load -
- External Hydraulic Device
- ,
- Compression
- ,
- Front Suspension
- UD Marzocchi TiN Coated Fork Full Adjustable (Pre-load, Compression, Rebound)
- Rear Wheel Travel
- 120 mm (4.7 inches)
- Front Wheel Travel
- 120 mm (4.7 inches)
- Rear Brakes Diameter
- 230 mm (9.1 inches)
- Front Brakes Diameter
- 320 mm (12.6 inches)
Available colors
Red/whiteyellow
