2012Sportbike
Bimota DB8
Key specifications
Engine
1198 cc
Power
170 HP
Torque
123 Nm
Weight
177 kg
Fuel type
petrol
Fuel capacity
4.8 L
Transmission
6-speed
Seat height
32 mm
Front brakes
Double disc. Floating discs, 4-Pistons
Rear brakes
Single disc. 2-pistons
Technical details
Source specification data
- Make
- Bimota
- Model
- DB8
- Category
- Sport
- Starter
- Electric
- Color Options
- White
- Power
- 170.00 HP (124.1 kW)) @ 9750 RPM
- Clutch
- Dry, multi-disc
- Torque
- 123.00 Nm (12.5 kgf-m or 90.7 ft.lbs) @ 8000 RPM
- Gearbox
- 6-speed
- Fuel System
- Injection. Walbro electronic injection
- Bore X Stroke
- 106.0 x 67.9 mm (4.2 x 2.7 inches)
- Compression
- 12.7:1
- Displacement
- 1198.00 ccm (73.10 cubic inches)
- Cooling System
- Liquid
- Engine Details
- V2, four-stroke
- Exhaust System
- 2 in 1 in 1, Titanium silencer.
- Lubrication System
- Wet sump
- Valves Per Cylinder
- 4
- Transmission Type Final Drive
- Chain
- Dry Weight
- 177.0 kg (390.2 pounds)
- Seat Height
- 800 mm (31.5 inches) If adjustable, lowest setting.
- Oil Capacity
- 3.00 litres (0.20 quarts)
- Fuel Capacity
- 18.00 litres (4.76 gallons)
- Overall Width
- 730 mm (28.7 inches)
- Overall Height
- 1,115 mm (43.9 inches)
- Overall Length
- 2,040 mm (80.3 inches)
- Ground Clearance
- 135 mm (5.3 inches)
- Power Weight Ratio
- 0.9605 HP/kg
- Rake
- 25.0°
- Trail
- 100 mm (3.9 inches)
- Rear Tyre
- 190/55-ZR17
- Frame Type
- NiCrMo4/aluminium
- Front Tyre
- 120/70-ZR17
- Rear Brakes
- Single disc. 2-pistons
- Front Brakes
- Double disc. Floating discs, 4-Pistons
- Rear Suspension
- Extreme Tech
- Front Suspension
- Marzocchi
- Rear Brakes Diameter
- 230 mm (9.1 inches)
- Front Brakes Diameter
- 320 mm (12.6 inches)
Available colors
White
