KTM XC 300 W
$11,949
Key specifications
Engine
293 cc
Weight
104 kg
Fuel type
petrol
Fuel capacity
9.0 L
Transmission
Manual, 6 speed, Chain
Seat height
963 mm
Front brakes
Hydraulic Disc
Rear brakes
Hydraulic Disc
Technical details
Source specification data
- Seats
- One
- -
- Seat Height (in/mm)
- 37.9 / 963
- Seat_type
- One-Piece
- Seat_location
- Driver
- Seat_material
- Vinyl
- Number_of_seats
- 1
- Seat_specifications
- Standard
- Brakes
- Brembo
- ®
- Front Brake Diameter (in/mm)
- 10.2 / 260
- Rear Brake Diameter (in/mm)
- 8.7 / 220
- Rear_brake_type
- Hydraulic Disc
- Brake_brand_name
- Brembo®
- Front_brake_type
- Hydraulic Disc
- Rear_brake_diameter_inmm
- 8.7 / 220
- Front_brake_diameter_inmm
- 10.2 / 260
- Engine
- Single
- -
- Engine Stroke2
- -
- Compression Ratio13
- .2:1
- Gas
- /
- Horsepower (bhp)
- 49
- Torque (Nm)
- 43.8
- Bore (mm/in)
- 72 / 2.83
- Stroke (in/mm)
- 2.83 / 72
- Displacement (cc/ci)
- 293.2 / 17.9
- Fuel Injector Size (mm)
- 39
- Torque
- (Nm)
- Cooling
- Liquid
- Starter
- Electric
- Bore_mmin
- 72 / 2.83
- Cylinders
- 1
- Fuel_type
- Gas / Oil Injected
- Torque_nm
- 43.8
- Horsepower
- (bhp)
- Carburetion
- Standard
- Engine_type
- Single-Cylinder
- Stroke_inmm
- 2.83 / 72
- Displacement
- 293.2 / 17.9
- Engine_stroke
- 2-Stroke
- Fuel_injector
- Yes
- Horsepower_bhp
- 49
- Carburetion_type
- Fuel Injected
- Carburetion_brand
- Keihin
- Compression_ratio
- 13.2:1
- Displacement_ccci
- 293.2 / 17.9
- Displacement_cc_ci
- 293
- Valve_configuration
- Reed Valve
- Compression_ratio132
- 1
- Fuel_injector_size_mm
- 39
- Engine_displacement_to_weight_cc
- 1.27
- Lights
- TypeLEDHeadlight (s)Standard
- Headlight_s
- Standard
- 132
- 1
- Type
- LED
- Clock
- Standard
- Glass
- Rearview MirrorsOptional
- Paint
- Standard
- Chromed
- No
- Dealers
- KTM Dealers
- Folding
- No
- Pricing
- P
- $11,949
- Warranty (Months/Condition)
- 1 /
- Reverse
- No
- Spoiler
- Optional
- Exterior
- ConstructionStandardFrameChromium MolybdenumBody MaterialPlasticFoot PegsStandardFoot Peg LocationDriverAdjustableNoHand GripsStandardHandlebarsStandardHandlebar PadsStandardExterior GuardsStandardBelt GuardNoBrush GuardNoDrive Shaft GuardNoExhaust GuardYesFork GuardsYesHand GuardsYesLight GuardNoSaddle Bag GuardNoTank GuardYesExterior CoversStandardFuel Tank CoverNoRadiator CoverYesSide CoverNoFront FenderStandardRear FenderStandardStandStandardStand TypeKickSpoilerOptionalSkid PlateStandard
- Metallic
- No
- Steering
- Steering ControlHandlebar
- Decal_kit
- Standard
- Foot_pegs
- Standard
- Lap_timer
- Optional
- Adjustable
- No
- Capacities
- Standard
- Carburetor
- No
- Hand_grips
- Standard
- Handlebars
- Standard
- Side_cover
- No
- Skid_plate
- Standard
- Tachometer
- Optional
- Convenience
- Heated Hand GripsOptionalAdjustable HandlebarsStandard
- Performance
- Standard
- Rear_fender
- Standard
- Construction
- Standard
- Front_fender
- Standard
- Paint_finish
- PaintStandardMetallicNoDecal KitStandard
- Trip_computer
- Standard
- Trip_odometer
- Standard
- Tube_tubeless
- Tubed
- Air_adjustable
- No
- Handlebar_pads
- Standard
- Identification
- Off
- -
- C
- 300
- Parent_company
- KTM
- Radiator_cover
- Yes
- Exterior_covers
- Standard
- Fuel_tank_cover
- No
- Rearview_mirrors
- Optional
- Steering_control
- Handlebar
- Foot_peg_location
- Driver
- Fuel_requirements
- Premium
- Heated_hand_grips
- Optional
- Destination_charge
- 650
- Adjustable_handlebars
- Standard
- Technical_specifications
- Wheelbase (in/mm)
- 58.6 / 1489
- Ground Clearance (in/mm)
- 13.7 / 347
- Dry Weight (lbs/kg)
- 230.6 / 104.6
- Fuel Capacity (gal/l)
- 2.4 / 9
- Fuel Capacity Reserve (gal/l)
- 0.4 / 1.5
- Engine Displacement
- to
- Weight (cc)
- 1.27
- Msrp
- 11,949
- Price
- Standard
- Warranty_monthscondition
- 1 / Limited
- Storage
- Storage CoverOptional
- Storage_cover
- Optional
- Frame
- Chromium Molybdenum
- Stand
- Standard
- Belt_guard
- No
- Stand_type
- Kick
- Tank_guard
- Yes
- Brush_guard
- No
- Hand_guards
- Yes
- Light_guard
- No
- Body_material
- Plastic
- Exhaust_guard
- Yes
- Exterior_guards
- Standard
- Saddle_bag_guard
- No
- Suspension
- Rear Adjustable Shock
- /
- Spring Pre
- -
- Front Suspension Size (in/mm)
- 1.9 / 48
- Front Travel (in/mm)
- 11.8 / 300
- Rear Travel (in/mm)
- 12.2 / 310
- Fork_guards
- Yes
- Rear_travel_inmm
- 12.2 / 310
- Front_travel_inmm
- 11.8 / 300
- Rear_suspension_type
- Twin Sided Swing Arm
- Front_suspension_type
- Inverted Fork
- Rear_suspension_material
- Aluminum
- Front_suspension_size_inmm
- 1.9 / 48
- Rear_suspension_brand_name
- WP XPLOR
- Front_suspension_brand_name
- WP XACT
- Number_rear_shock_absorbers
- 1
- Front_central_suspension_strut
- No
- Rear_adjustable_rebound_damping
- Yes
- Front_adjustable_rebound_damping
- Yes
- Rear_adjustable_shock_spring_preload
- Yes
- Overdrive
- Yes
- Speedometer
- Standard
- Transmission
- TransmissionStandardTransmission BrandPanklTransmission TypeManualNumber Of Speeds6OverdriveYesReverseNoPrimary Drive (Rear Wheel)Chain
- Number_of_speeds
- 6
- Drive_shaft_guard
- No
- Transmission_type
- Manual
- Transmission_brand
- Pankl
- Primary_drive_rear_wheel
- Chain
- Tires
- Standard
- Wheels
- Standard
- Tire_brand
- Dunlop®
- Wheels_tires
- Tube
- /
- Dunlop
- ®
- Front Wheel Width (in)
- 1.6
- Rear Wheel Width (in)
- 2.15
- Dunlop
- ®
- T82
- 80/1000
- Dunlop
- ®
- T82
- 110/100
- Wheels_composition
- Aluminum
- Rear_tire_full_spec
- Dunlop® AT82 110/100 R18
- Rear_wheel_diameter
- 18
- Front_tire_full_spec
- Dunlop® AT82 80/1000 R21
- Front_wheel_diameter
- 21
- Generic_type_primary
- Off-Road
- Rear_tire_aspect_ratio
- 100
- Front_tire_aspect_ratio
- 100
- Make
- KTM
- Year
- 2026
- Introduction_year
- 2019
- Manufacturer_country
- Austria
- Manufacturer_recommend_minimum_age
- 16
- Display_name
- XC 300 W
- Instrumentation
- Digital InstrumentationStandardClockStandardSpeedometerStandardTachometerOptionalTrip OdometerStandardTrip ComputerStandardLap TimerOptionalFuel Level WarningStandardFuel Level Warning TypeLight
- Fuel_level_warning
- Standard
- Digital_instrumentation
- Standard
- Fuel_level_warning_type
- Light
- Weight
- Standard
- Wheelbase
- (in/mm)
- Dimensions
- Standard
- Seat_height
- (in/mm)
- Fuel_capacity
- Reserve (gal/l)
- Wheelbase_inmm
- 58.6 / 1489
- Rear_tire_width
- 110
- Dry_weight_lbskg
- 230.6 / 104.6
- Front_tire_width
- 80
- Seat_height_inmm
- 37.9 / 963
- Fuel_capacity_gall
- 2.4 / 9
- Rear_wheel_width_in
- 2.15
- Front_wheel_width_in
- 1.6
- Ground_clearance_inmm
- 13.7 / 347
- Fuel_capacity_reserve_gall
- 0.4 / 1.5
