Back to Bike FinderYears: 2024
2024ATV
Kymco MXU 500i T3B EPS
Key specifications
Engine
499 cc
Torque
39 Nm
Weight
329 kg
Fuel type
petrol
Fuel capacity
5.6 L
Transmission
2000-speed
Front brakes
Double disc. Combined braking system (CBS)
Rear brakes
Single disc
Technical details
Source specification data
- Make
- Kymco
- Model
- MXU 500i T3B EPS
- Category
- ATV
- Starter
- Electric
- Color Options
- Green
- Carrying Capacity
- Heavy
- -
- Duty Front
- and
- Torque
- 38.8 Nm (4.0 kgf-m or 28.6 ft.lbs) @ 5500 RPM
- Gearbox
- 2000-speed
- Ignition
- CDI
- Driveline
- H
- -
- L
- -
- N
- -
- R
- -
- Differential Lock
- . 2
- D
- /4
- D
- .
- Engine Type
- Single cylinder, four-stroke
- Fuel System
- Injection. EFI
- Bore X Stroke
- 92.0 x 75.4 mm (3.6 x 3.0 inches)
- Displacement
- 499.0 ccm (30.45 cubic inches)
- Cooling System
- Liquid
- Valves Per Cylinder
- 4
- Transmission Type Final Drive
- Belt (final drive)
- Dry Weight
- 329.0 kg (725.3 pounds)
- Fuel Capacity
- 21.00 litres (5.55 US gallons)
- Overall Width
- 1245 mm (49.0 inches)
- Overall Height
- 1250 mm (49.2 inches)
- Overall Length
- 2140 mm (84.3 inches)
- Ground Clearance
- 265 mm (10.4 inches)
- Power Weight Ratio
- 0.1018 HP/kg
- Rear Tyre
- 25/10-12
- Front Tyre
- 25/8-12
- Rear Brakes
- Single disc
- Front Brakes
- Double
- disc.
- Combined
- braking system (
- S
- )
- Rear Suspension
- Dual A-Arm, IRS
- Front Suspension
- Dual A-Arm
Available colors
Green
