2012Off-road
TM Racing MX 300
Key specifications
Engine
294 cc
Fuel type
petrol
Fuel capacity
2.3 L
Transmission
5-speed
Front brakes
Single disc. Braking wave disk. With Nissin pump and caliper
Rear brakes
Single disc. Braking wave disk. With Nissin pump and caliper
Technical details
Source specification data
- Make
- TM Racing
- Model
- MX 300
- Category
- Cross-motocross
- Comments
- Italian made bike.
- Color Options
- Blue/white
- Clutch
- Multiple-disk in oil bath with hydraulic control
- Gearbox
- 5-speed
- Ignition
- Kokusan CDI Electronic with variable advance with two selectable maps
- Driveline
- Primary drive: Straight – tooth gear
- Engine Type
- V-Force Reed intake valve
- Fuel System
- Carburettor. Keihin PWM 38
- Bore X Stroke
- 72.0 x 72.0 mm (2.8 x 2.8 inches)
- Displacement
- 294.00 ccm (17.94 cubic inches)
- Cooling System
- Liquid
- Engine Details
- Single cylinder, two-stroke
- Lubrication System
- 3.5% mixture
- Transmission Type Final Drive
- Chain
- Fuel Capacity
- 8.70 litres (2.30 gallons)
- Wheels
- Blue rims.
- Rear Tyre
- 100/90-19
- Frame Type
- Perimetral aluminium
- Front Tyre
- 80/100-21
- Rear Brakes
- Single
- disc.
- Braking
- wave disk.
- With Nissin
- pump and caliper
- Front Brakes
- Single
- disc.
- Braking
- wave disk.
- With Nissin
- pump and caliper
- Rear Suspension
- Sachs Boge, optional Ohlins
- Front Suspension
- Marzocchi USD 50mm
- Rear Brakes Diameter
- 245 mm (9.6 inches)
- Front Brakes Diameter
- 270 mm (10.6 inches)
Available colors
Blue/white
