Back to Bike FinderYears: 2012
2012Super Moto
TM Racing SMM 530F WD
Key specifications
Engine
528 cc
Fuel type
petrol
Fuel capacity
2.2 L
Transmission
5-speed
Front brakes
Single disc. Radial pump and Brembo caliper
Rear brakes
Single disc. Nissin pump and Brembo caliper
Technical details
Source specification data
- Make
- TM Racing
- Model
- SMM 530F WD
- Category
- Super motard
- Starter
- Electric & kick
- Comments
- Italian bike.
- Color Options
- White
- Gearbox
- 5-speed
- Ignition
- Kokusan CDI Electronic with variable advance
- Fuel System
- Carburettor. Mikuni
- Bore X Stroke
- 98.0 x 70.0 mm (3.9 x 2.8 inches)
- Displacement
- 527.70 ccm (32.20 cubic inches)
- Cooling System
- Liquid
- Engine Details
- Single cylinder, four-stroke
- Lubrication System
- Dry sump with double rotor pump
- Valves Per Cylinder
- 4
- Transmission Type Final Drive
- Chain
- Fuel Capacity
- 8.20 litres (2.17 gallons)
- Wheels
- 5-spoke
- Rear Tyre
- 150/60-ZR17
- Frame Type
- Aluminium perimeter
- Front Tyre
- 120/70-ZR17
- Rear Brakes
- Single
- disc.
- Nissin
- pump and
- Brembo
- caliper
- Front Brakes
- Single
- disc.
- Radial
- pump and
- Brembo
- caliper
- Rear Suspension
- Sachs Boge ( optional Ohlins )
- Front Suspension
- Ohlin USD 46mm
- Rear Brakes Diameter
- 220 mm (8.7 inches)
- Front Brakes Diameter
- 320 mm (12.6 inches)
Available colors
White
