Back to Bike FinderYears: 2006
2006Super Moto
Yamaha DT 50 X
Key specifications
Engine
50 cc
Power
2 HP
Torque
3 Nm
Weight
105 kg
Fuel type
petrol
Fuel capacity
3.7 L
Transmission
5-speed
Seat height
34 mm
Front brakes
Single disc
Rear brakes
Single disc
Technical details
Source specification data
- Make
- Yamaha
- Model
- DT 50 X
- Category
- Super motard
- Starter
- Kick
- Power
- 2.14 HP (1.6 kW)) @ 6000 RPM
- Torque
- 3.10 Nm (0.3 kgf-m or 2.3 ft.lbs) @ 4000 RPM
- Gearbox
- 5-speed
- Ignition
- Electronic (CDI)
- Fuel System
- Carburettor. Dell´Orto PHBN 16
- Bore X Stroke
- 40.3 x 39.0 mm (1.6 x 1.5 inches)
- Compression
- 12.0:1
- Displacement
- 50.00 ccm (3.05 cubic inches)
- Engine Details
- Single cylinder, two-stroke
- Lubrication System
- Automatic pump with variable displacement
- Transmission Type Final Drive
- Chain
- Dry Weight
- 105.0 kg (231.5 pounds)
- Seat Height
- 870 mm (34.3 inches) If adjustable, lowest setting.
- Fuel Capacity
- 13.80 litres (3.65 gallons)
- Overall Width
- 850 mm (33.5 inches)
- Overall Height
- 1,115 mm (43.9 inches)
- Overall Length
- 2,000 mm (78.7 inches)
- Ground Clearance
- 317 mm (12.5 inches)
- Power Weight Ratio
- 0.0204 HP/kg
- Rear Tyre
- 130/70-17
- Frame Type
- Front suspension system
- Front Tyre
- 100/80-17
- Rear Brakes
- Single disc
- Front Brakes
- Single disc
- Rear Suspension
- Hydraulic unit swing
- Front Suspension
- Hydraulic and telescopic fork
- Rear Brakes Diameter
- 218 mm (8.6 inches)
- Front Brakes Diameter
- 259 mm (10.2 inches)
