Back to Bike FinderYears: 2019 · 2018
2019Other
Yamaha MT-09 TR
Key specifications
Engine
847 cc
Power
115 HP
Torque
88 Nm
Fuel type
petrol
Fuel capacity
4.8 L
Transmission
6-speed
Seat height
34 mm
Front brakes
Double disc. Hydraulic. ABS.
Rear brakes
Single disc. Hydraulic. ABS.
Technical details
Source specification data
- Make
- Yamaha
- Model
- MT-09 TR
- Category
- Sport touring
- Starter
- Electric
- Color Options
- Nimbus Grey
- Factory Warranty
- 1 Year Limited Factory Warranty
- Power
- 115.00 HP (83.9 kW)) @ 10000 RPM
- Torque
- 87.50 Nm (8.9 kgf-m or 64.5 ft.lbs) @ 8900 RPM
- Gearbox
- 6-speed
- Ignition
- TCI
- Fuel System
- Injection
- Bore X Stroke
- 78.0 x 59.1 mm (3.1 x 2.3 inches)
- Compression
- 11.5:1
- Displacement
- 847.00 ccm (51.68 cubic inches)
- Cooling System
- Liquid
- Engine Details
- In-line three, four-stroke
- Fuel Consumption
- 4.30 litres/100 km (23.3 km/l or 54.70 mpg)
- Greenhouse Gases
- O2
- g/km. (
- O2
- -
- Carbon
- dioxide emission)
- Lubrication System
- Wet sump
- Valves Per Cylinder
- 4
- Transmission Type Final Drive
- Chain
- Seat Height
- 850 mm (33.5 inches) If adjustable, lowest setting.
- Oil Capacity
- 3.40 litres (0.22 quarts)
- Fuel Capacity
- 18.17 litres (4.80 gallons)
- Overall Width
- 850 mm (33.5 inches)
- Overall Height
- 1,375 mm (54.1 inches)
- Overall Length
- 2,160 mm (85.0 inches)
- Ground Clearance
- 135 mm (5.3 inches)
- Alternate Seat Height
- 865 mm (34.1 inches) If adjustable, highest setting.
- Weight Incl Oil Gas Etc
- 214.0 kg (471.8 pounds)
- Rake
- 24.0°
- Trail
- 100 mm (3.9 inches)
- Rear Tyre
- 180/55-ZR17
- Frame Type
- Diamond
- Front Tyre
- 120/70-ZR17
- Rear Brakes
- Single disc. Hydraulic. ABS.
- Front Brakes
- Double disc. Hydraulic. ABS.
- Rear Suspension
- Single shock, adjustable preload and rebound damping
- Front Suspension
- 41mm inverted fork, adjustable preload and rebound damping
- Rear Wheel Travel
- 130 mm (5.1 inches)
- Front Wheel Travel
- 137 mm (5.4 inches)
- Rear Brakes Diameter
- 245 mm (9.6 inches)
- Front Brakes Diameter
- 298 mm (11.7 inches)
Available colors
Nimbus Grey
